Description
RMF Mini Water Vac MWV1A30G1B060000, vacuum dehydration unit, frame mounted, PLC controlled. Incl. 2 kW heater, vacuum pump and chamber, RMF offline filter unit (with 30G1B element) and RMF air conditioner ACL96R. Flow approx. 2 l/min.
Article number: RMF009268884 – OEM: 9268884.
The RMF purifier MWV1A30G1B060000 is a vacuum dehydration unit that removes water, gas and solid contamination, which are corrosive and contribute to the reduction of machine life.
Water, gas and solid particle contamination greatly increase maintenance costs and contribute to unwanted break downs or total machine failures. The RMF Mini Water Vac offers protection against malfunctions, break downs and total failures.
Operation
The RMF purifier MWV1A30G1B060000 does not require continuous attention whilst operating, once connected properly and commissioned, oil purification is a semi-automatic, PLC controlled process.
Plug and play
The RMF vacuum dehydration units can easily be connected to your system, and can be used while the system is turned off or running. Just plug and play, get started and be amazed how fast water will be extracted.
Technical specification
Total power output: 2,6 kW
Flow: approx. 2 l/min
Electric power supply: 230/400 VAC – 50/60 Hz 3Phase
Inlet connection: G 1″ BSP Female
Outlet connection: G 1/2″ BSP Female
Heating power: 2 kW
Max. suction pressure: 1 bar
Max. return pressure: 1 bar
Dimensions H x W x D (mm): 1100 x 740 x 450
